Accent wall plans from a trim carpenter

Measurements in,
cut list out.

Skip the math. Type your wall size and get the drawing, every cut length, and the order to nail them up.

Design your wall

Floor to ceiling, baseboard included.

See your wall in every style →

Free calculators for spacing. Full plans — drawings, cut list, install steps — $25.

Pinwheel accent wall in a gold foyer
The product

Every board is cut to your wall, not a standard size.

Tap a style to start building.

Measured wrong?
Fix it. The plan redraws.

Most accent wall plans sold online are made to order. You send your measurements, wait for a designer to draw it, and what comes back is a PDF for that one wall at that one size. Measure wrong and you buy it again. Change your mind on the pattern and you start over. Here the drawing is the app, so the numbers move with you until you're ready to print.

Instant Wall

Type the right number. Done.

  • Adjust up to 10" either way, any time
  • Switch to any other style at that size
  • Drawing and cut list rebuild while you watch
  • A typo costs you nothing
Everyone else

Wrong measurement, final sale.

  • Send measurements, wait weeks for a drawing
  • One wrong number and the plan is useless
  • Changed your mind? Order again
  • No refunds on custom work
Sheet 2 — Cut listwhat to cut
#ShapePieceLong ptEnd cuts
1panel moulding44″1 5/8″
2panel moulding84 1/2″1 5/8″
3panel moulding44″1 5/8″
4panel moulding84 1/2″1 5/8″
5panel moulding44″1 5/8″
6panel moulding84 1/2″1 5/8″
7panel moulding44″1 5/8″
8panel moulding84 1/2″1 5/8″
9panel moulding44″1 5/8″
10panel moulding84 1/2″1 5/8″
11panel moulding44″1 5/8″
12panel moulding84 1/2″1 5/8″

Take-off · cut all of one length in a single run
6 × 84 1/2″ × 1 5/8″ panel moulding
6 × 44″ × 1 5/8″ panel moulding

Install in number order · • hook the tape · × mark the length
Every length is long point. Read it straight off the saw.

Sheet 1, the elevation, and Sheet 3, the build steps
Sheet 1 — Elevationwhere it goes

Every board on the drawing, every board on the list.

Sheet 3 — Build stepshow to hang it
  1. 1. CHECK THE WALL.
  2. 2. GATHER MATERIAL.
  3. 3. MEASURING ANGLED PIECES.
  4. 4. CUT AND LABEL.
  5. 5. LAY OUT THE BOXES.
  6. 6. INSTALL IN NUMBER ORDER.
  7. 7. FASTEN.
  8. 8. IF A PIECE RUNS LONG.
  9. 9. FINISH.

Verify in field before cutting. Ceilings and floors are rarely level.

Design free. $25 to print.

$25 CAD
One wall, tax included, yours forever
Design your wall →

Your wall is saved forever. Your wall link opens it on any device, next weekend or next year — same wall, same plan, still adjustable.

Built from these plans

Every photo below was built from an Instant Wall cut list. Work out your spacing free, then unlock the full plan for the wall you pick.

Shaker accent wall in a gray bedroom
Shaker Feature Wall
Design your wall - get your build plan instantly
Shaker wall in a gray bedroom.
Interior board and batten accent wall in a beige bedroom
Board & Batten
Design your wall - get your build plan instantly
Interior board and batten wall in a beige bedroom.
Panel moulding accent wall in a white living room
Panel Moulding
Design your wall - get your build plan instantly
Panel moulding wall in a white living room.
Picture-frame wainscoting in a blue dining room
Picture-Frame Wainscoting
Design your wall - get your build plan instantly
Picture-frame wainscoting in a blue dining room.
Slat accent wall in a dark green bedroom
Slat
Design your wall - get your build plan instantly
Slat wall in a green bedroom.
Peaks and ladders accent wall in a white dining room
Peaks and Ladders
Design your wall - get your build plan instantly
Peaks and ladders wall in a white dining room.
Chevron accent wall in a white dining room
Chevron
Design your wall - get your build plan instantly
Chevron wall in a white dining room.
Cascade accent wall in a green living room
Cascade
Design your wall - get your build plan instantly
Cascade wall in a green living room.
Diamond accent wall in a blue dining room
Diamond
Design your wall - get your build plan instantly
Diamond wall in a blue dining room.
Interior board and batten accent wall in a black bedroom
Board & Batten
Design your wall - get your build plan instantly
Interior board and batten wall in a black bedroom.
Panel moulding accent wall in a white bedroom
Panel Moulding
Design your wall - get your build plan instantly
Panel moulding wall in a white bedroom.
Shaker accent wall in a teal dining room
Shaker Feature Wall
Design your wall - get your build plan instantly
Shaker wall in a teal dining room.
Rain accent wall in a charcoal living room
Rain
Design your wall - get your build plan instantly
Rain wall in a charcoal living room.
Mirror chevron accent wall in a navy living room
Mirror Chevron
Design your wall - get your build plan instantly
Mirror chevron wall in a navy living room.
Pinwheel accent wall in a gold foyer
Pinwheel
Design your wall - get your build plan instantly
Pinwheel wall in a gold foyer.

Get the full plan →
instant — plans the moment you pay

A weekend,
not a project.

  1. Measure the wall

    Width and height. Add the door or outlet if one's in the way and the pattern works around it.

  2. Tune it live

    Change the style, board width, spacing. The drawing and cut list redraw while you watch.

  3. Print and build

    Three sheets to your printer or phone. Buy your boards and start cutting the same day.

Pricing

Design free. Pay for the plan.

See your wall drawn in every style before a dollar changes hands.

$25 CAD
One wall · tax included · yours forever
  • Scaled elevation, every board numbered
  • Full cut list, long point, to the sixteenth
  • Numbered install order with build steps
  • Adjust dimensions up to 10". Plan rebuilds free
  • Saved forever, opens on any device
  • Print-ready PDF, no watermark
Design your wall

Doing this for a living? Unlimited walls, coming soon →

Accent wall questions, answered by a trim carpenter

These are the questions we get asked on site, answered the way we would answer them standing in the room.

How long does it take to build an accent wall?

One wall, two days, and only one of them is work. A 12-foot interior wall of board and batten is a morning of measuring and cutting, an afternoon of nailing, then filler and caulk before you stop. Day two is sanding the filler and two coats of paint. What goes wrong is rushing the caulk. It needs to skin over before paint or it drags and you see every bead. If you are working the layout out on the wall as you go, add half a day and expect to waste a few pieces.

What material should I use?

Primed MDF for anything that gets painted and stays dry. It is flat, it has no grain to telegraph through paint, and it is the cheapest of the three. Poplar if the wall is in a hallway or beside a door where it takes knocks — MDF dents and the dent stays. Pine only if you are staining, and even then knots bleed through paint no matter how many coats go on, so it wants a shellac-based primer first. Do not use MDF in a bathroom or a basement that has ever been damp. It swells at the bottom edge and never comes back.

What tools do I need?

A miter saw, a brad nailer, a 4-foot level, a tape, a caulk gun and a stud finder. That is the whole list. You can rent the saw and the nailer for a day for less than the wood costs. A hand saw and a miter box works and it is slower than people think. A wall with twenty battens is forty cuts. A laser level saves more time than anything else you can add, because it puts your rail line on the wall in one shot instead of walking a level across it.

How do I measure my wall?

Width and height in inches, to the sixteenth. Measure the width at the top, the middle and the bottom, and use the smallest one. Walls are not square, and the number that matters is the one your top rail has to fit into. Height is floor to ceiling at both ends. If there is a window in the wall, measure from the left edge of the wall to the left edge of the opening, plus the opening's own width and height. Everything after that is layout, and layout is arithmetic nobody should be doing on a phone at nine at night.

Do I need to take the baseboard off?

Three ways to do it and they are not the same job. Leave it and land the battens on top of it — fastest, and the battens sit proud of the baseboard by whatever the baseboard is thick, which reads unfinished unless the battens are thicker. Take it off and reinstall it over the bottom rail — the cleanest look, and the reason most finished walls you have seen look the way they do. Or run a flat bottom rail and no baseboard at all, which is the modern read and the easiest to paint. Pick before you cut. The batten length changes with the answer.

Where do outlets and vents go?

In the gaps, never on a batten. An outlet under a batten means cutting the batten around the box, adding an extension ring, and a plate sitting half on wood and half on drywall. Move the layout instead. Shift the field an inch or two and let the spacing absorb it. This is the most common reason a wall that looked right on paper looks wrong on the wall, and it is also why a pre-cut kit cannot help you. A kit assumes a clean rectangle.

Do I have to hit studs?

No. Trim this light holds on construction adhesive and 18-gauge brad nails into drywall. Studs are worth finding for the top rail if you are putting a shelf ledge on it, and for nothing else. What matters more is nailing at an angle. Two brads toed in opposite directions hold better than four driven straight.

How much paint do I need for an accent wall?

One gallon covers a normal accent wall with two coats, battens and all, with paint left over. The battens add surface but almost no square footage. A 12 by 8 wall is 96 square feet and twenty battens add maybe 25 more. Buy the gallon, not two quarts. Spray it if you own a sprayer; a 4-inch roller with a brush for the edges gets the same result in about three times the time.

What does an accent wall cost in materials?

Between $80 and $200 for a normal wall, depending on what you build it from and how tall it is. Primed MDF at the low end, poplar at the high end. Add a tube of adhesive, a tube of paintable caulk, a tub of filler and a gallon of paint. What people underestimate is not the wood. It is the second trip to the store, and the second trip happens because the cut list was wrong.

Build your wall like a pro!

Built by a working trim carpenter. Every pattern is field-tested. Every cut list has been used on a real wall.

Start building today
